轮辐称重传感器
产品描述
参数
产品特点:
- 低截面紧凑设计;
- 高输出小形变;
- 高精度、高稳定性。
- 可定制大吨位量程。
- 可配套三合一、四合一。
产品参数:
型号(Model) | 单位 | RHL-2T-2.0-Ⅱ-C2 |
---|---|---|
量程(Capacity) | T | 2T |
输出灵敏度(Rated output) | mV/V | 2.0±0.004 |
精度等级(Accuracy class) | %FS | C2 |
综合误差(Combined erro) | %FS | ≤±0.05 |
蠕变(Creep) | %FS/30min | 0.02 |
温度灵敏度漂移(Temperature effect on sensitivity) | %FS/10℃ | 0.05 |
温度零点漂移(Temperature effect on zero) | %FS/10℃ | 0.05 |
零点平衡(Zero balance) | %FS | ±1.0 |
输入阻抗(Input resistance) | Ω | 2060±20 |
输出阻抗(Output resistance) | Ω | 2000±5 |
绝缘电阻(Insulation resistance) | MΩ(50V) | 1000 |
推荐激励电压(Recommended excitation voltage) | V | 10~18 |
温度补偿范围(Compensated temperature range) | ℃ | 0~60 |
工作温度范围(Operating temperature range) | ℃ | -30~ |
